Designed for curb pump self-service stations and highly sensitive electronic fuel pumps.
Tube: NBR/PVC, RMA Class A. Cover: Thermalon™, U/L approved, Class B. Reinforcement: Spiral polyester cord with static wire (Softwall.
-40°C to +82°C (-40°F to +180°F)
| Part Number | I.D. Inches | O.D. Inches | MAX W.P. (PSI) | Approx. Wt. Per. Ft. Lbs. |
| HFD062GACP-TH | 5/8 | 1.03 | 200 | 0.27 |
| HFD075GACP-TH | 3/4 | 1.13 | 200 | 0.32 |
| HFD100GACP-TH | 1 | 1.50 | 150 | 0.62 |
